Grizzly G0520 Drill Press w/ Cross Sliding Table & Power Feed
Posted by – April 18, 2010
Product Description
This is an excellent buy in a heavy-duty Drill Press. Equipped with a cross sliding table & power feed, this machine is robust enough for milling, drilling & boring. & the head is adjustable on the column! This feature expands the capacity of this machine. You can also change speeds quickly & easily. Equipped with a drawbar for threaded end-mill tooling. SPECIFICATIONS: Motor size: 2 HP Drilling capacity: 1-1/4″ End milling capacity: 7/8″ Face milling capacity: 3″ Spindle travel: 5-1/8″ Max. distance spindle to table: 31″ Max. distance spindle to base: 51-1/8″ Number of speeds: 12 Spindle taper: MT #3 Range of speeds: 140 – 2570 RPM Swing: 16″ Cross table size: 23″ x 7-1/2″ Longitudinal travel: 14-1/2″ Cross travel: 7-3/32″ Approximate shipping weight: 780 lbs.
Grizzly G0520 Drill Press w/ Cross Sliding Table & Power Feed
Grizzly G7947 12 Speed 17″ Floor Drill Press
Posted by – April 17, 2010
Product Description
If you use your drill press commercially and need power and capacity, this is one drill press you should look at seriously. Note the 4-3/4″ spindle travel! Specifications: *Motor size: 1 H.P., Single-Phase, 110V/220V *Overall height: 70″ *Swing: 17″ *Spindle travel: 4-3/4″ *Number of speeds: 12 *Drill chuck: 5/8″ *Spindle taper: MT #3 *Range of speeds: 210, 310, 400, 440, 630, 670, 1260, 1430, 1650, 2050, 2350, 3300 RPM *Drilling capacity: 1″ steel *Table: Precision ground cast iron *Table size: 13-5/8″ sq. *Table tilts: 90 in both directions *Approx. shipping weight: 283 lbs. *Includes built-in light (bulb not included).
Grizzly G7947 12 Speed 17″ Floor Drill Press
Grizzly G7942 5 Speed Baby Drill Press
Posted by – April 12, 2010
- Drill chuck: 1-64″ – 1/2″ (1-13mm)
- Drilling capacity: 1/2″ steel
- Motor: 1/3 H.P., TEFC motor, 110V
- Number of speeds: 5 (620, 1100, 1720, 2340, 3100 RPM)
- Swing: 8″
Product Description
Perfect for the small shop, this tough little guy won’t get in your way when things get cramped. Put it away on the shelf when finished. Very cute unit! Specifications: Motor: 1/3 H.P., TEFC motor, 110V Overall height: 23″ Spindle travel: 2″ Number of speeds: 5 (620, 1100, 1720, 2340, 3100 RPM) Drill chuck: 1/64″ – 1/2″ (1-13mm) Swing: 8″ Drilling capacity: 1/2″ steel Table: Precision ground cast iron Table swing: 360 Approx. shipping weight: 45 lbs. Table tilts: 90 left and right
Grizzly G7942 5 Speed Baby Drill Press
Grizzly G7943 12 Speed Heavy-Duty Bench-Top Drill Press
Posted by – April 12, 2010
Product Description
All the features and dependability of an expensive industrial grade drill press – with a price tag that’s astoundingly low. Includes built-in light (bulb not included). Specifications: Motor: 3/4 HP, 110V Overall height: 38″ Spindle travel: 3-1/4″ Number of speeds: 12 Drill chuck: 1/64″ – 5/8″ (1-16mm) Spindle taper: MT #2 Range of speeds: 140, 260, 320, 380, 480, 540, 980, 1160, 1510, 1650, 2180, 3050 RPM Swing: 14″ Drilling capacity: 3/4″ steel Table: Precision ground cast iron Table tilts: 90 in both directions Table swing: 360 Approx. shipping weight: 154 lbs.
Grizzly G7943 12 Speed Heavy-Duty Bench-Top Drill Press
Grizzly G8689 Mini Milling Machine
Posted by – January 17, 2010
Product Description
Now here is a mini milling machine that has more features than some Mill/Drills & is affordable for everyone! This little brute will handle any kind of job up to 1/2″ drilling, 1/2″ end mills & 1″ facing. No belt changes necessary! The variable speed control & gear drive saves you time & hassle. Truly, a remarkable machine Features: Dovetail column Safety shut off switch Adjustable depth stop Fine feed head control Geared drive Clear guard on spindle Rubber chip guards on ways Zero setting dials Dials read inches Adjustable dovetail ways on column 3/8″ & 1/2″ collets 1/2″ drill chuck 2 T-nuts Specifications: Spindle Taper: MT #3 Head Travel: 7-1/2″ Head Tilt: 45 degrees L/R Max. distance spindle to table: 11-1/2″ Swing: 12-3/4″ Longitudinal Travel: 7-5/16″ Cross-slide travel: 4″ Table size: 3-5/8″ x 15-3/4″ Speeds: Variable Speed Range: 0-2500 RPM Motor Size: 3/4 HP Shipping Weight: 149 lbs.
Grizzly G8689 Mini Milling Machine
Grizzly G0521 Drilling/Tapping Machine
Posted by – January 16, 2010
Product Description
This is a sophisticated Tapping Machine with all the features you’d expect, like auto-reverse, precision collet set for taps, foot pedal control, massive construction & 2 HP of brute force! It also is a precision drill press, too! It has nine spindle speeds, a swing of 18″ & 5-1/8″ of spindle stroke. Without a doubt, this is a great buy all around. SPECIFICATIONS: Motor size: 2 HP, 3-phase Voltage: 220V Switch: Reversing Overall height: 69-1/4″ Spindle travel: 5-1/8″ Number of speeds: 9 Spindle taper: MT#3 Range of speeds: 190 – 2250 RPM Swing: 18″ Max. distance spindle to table: 30″ Max. distance spindle to base: 46″ Tapping capacity: 7/8″ Collet sizes for taps: 1/4″, 5/16″, 3/8″, 1/2″, 9/16″, 5/8″, 11/16″, 3/4″, 13/16″ & 7/8″ Table size: 13-3/8″ x 14-1/8″ Head swivel: 360 Drilling capacity: 1″ in Mild Steel Approximate shipping weight: 656 lbs.
Grizzly G0521 Drilling/Tapping Machine
Grizzly H8028 Pen Press
Posted by – January 8, 2010
Product Description
Press pen segments together with controlled lever action. A sliding rod adjusts for progressively longer segments. Includes long lever handle and two alignment pins. Indispensable for any pen maker!
Grizzly G7946 5 Speed Floor Radial Drill Press
Posted by – January 3, 2010
Product Description
This 5 speed floor radial drill press features variable swing up to 34″ and pivoting heads for drilling at just about any angle. Truly versatile! Specifications: *Motor: 1/2-HP, 110V *Overall Height: 64-1/2″ *Spindle travel: 3-1/4″ *Number of speeds: 5 *Drill chuck: 1/8″-5/8″ *Range of speeds: 550, 880, 1520, 2490, 3470 RPM *Swing: 34″ maximum *Table: Precision ground cast iron *Table size: 12-3/4″ Dia. *Table swing: 360 *Table tilts: 90 in both directions *Approx. shipping weight: 147 lbs. Please see item G7945 for a bench-top model of this machine.
Grizzly G7946 5 Speed Floor Radial Drill Press
Grizzly G0520 Drill Press w/ Cross Sliding Table & Power Feed
Posted by – January 2, 2010
Product Description
This is an excellent buy in a heavy-duty Drill Press. Equipped with a cross sliding table & power feed, this machine is robust enough for milling, drilling & boring. & the head is adjustable on the column! This feature expands the capacity of this machine. You can also change speeds quickly & easily. Equipped with a drawbar for threaded end-mill tooling. SPECIFICATIONS: Motor size: 2 HP Drilling capacity: 1-1/4″ End milling capacity: 7/8″ Face milling capacity: 3″ Spindle travel: 5-1/8″ Max. distance spindle to table: 31″ Max. distance spindle to base: 51-1/8″ Number of speeds: 12 Spindle taper: MT #3 Range of speeds: 140 – 2570 RPM Swing: 16″ Cross table size: 23″ x 7-1/2″ Longitudinal travel: 14-1/2″ Cross travel: 7-3/32″ Approximate shipping weight: 780 lbs.
Grizzly G0520 Drill Press w/ Cross Sliding Table & Power Feed
